Trek FX+ 1 All-Road Electric Hybrid Bike – Midstep Frame

Description

FX+ 1 Midstep is a versatile and fast throttle e-bike built for cruising through town with an ear-to-ear grin. Its handlebar throttle makes getting up to speed a breeze, and pedal assist gives you a smooth boost while you ride. Plus, an EasyMag magnetic charger with a sleek, portable wall-mounted system makes charging between rides easier than ever.

Features:

• With the push of a button, the easy-to-use throttle lets you flatten hills, ride further, and adventure longer, without breaking a sweat.
• FX+ 1 comes equipped with a bright, rear taillight with an integrated brake light and turn signals for increased visibility on the road.
• Designed with a hassle-free magnetic attachment to charge, bright LED status lights, and an optional wall mount, EasyMag lets you charge at home or on the go.
• FX+ 1 pairs with the Trek Central app so you can easily adjust your bike’s settings for longer range, map the perfect routes, track your ride stats, and so much more.

Specs:

Frameset

Frame: Alpha Gold Aluminum, internal cable routing, internal battery, rack & fender mounts, flat mount disc brake, kickstand mount, 144.5mm OLD hub motor spacing

Fork: Alloy, internal brake routing, fender mounts, rack mounts, ThruSkew 5mm bolt-on skewer

Wheels

Front Hub: Alloy low-flange w/6-bolt disc, 36h, w/QR

Front Skewer: 132x5mm QR, ThruSkew

Rim Size: Alloy double wall, 36h

Tire: Bontrager GR0 Comp, wire bead, 60 tpi, 650x50mm

Max Tire Size: 650x50mm

E-System

Battery: 520Wh, integrated in down tube

Charger: Trek Easy Mag charger, 2.7A, 54.9V output, 100V-240V AC input

Computer: LCD display

Motor: Hub drive motor, 60 Nm, 500W, 36H, black

Drivetrain

Shifter: Shimano M315, 8 speed

Rear derailleur: Shimano ESSA U2000

Crank: Alloy, 40T steel chainring, 170mm length

Cassette: Shimano HG400, 11-45, 8 speed

Chain: KMC Z8.3

Pedal: Bontrager City pedals

Max Chainring Size: 1x:40T

Components

Saddle: Bontrager Sport Women’s

Seatpost:

• Sizes S, M: Bontrager alloy, 31.6mm, 12mm offset, 330mm length
• Size L: Bontrager alloy, 31.6mm, 12mm offset, 400mm length

Handlebar:

• Size S, M: Bontrager alloy, 31.8mm, 15mm rise, 690mm width
• Size L: Bontrager alloy, 31.8mm, 15mm rise, 720mm width

Grips: Bontrager XR Endurance Comp, lock-on

Stem:

• Size S, M: Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length
• Size L: Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 90mm length

Brake: Rush BH-286 hydraulic disc, 180mm rotor

Rotor Size: Max brake rotor sizes: 180mm front & rear

Accessories

Lights: Herrmans MR8, 180 lumen, 60 lux, LED headlight & Sate-Lite M-15 with turn signal and brake light function

Kickstand: Adjustable length alloy kickstand

Weight

M – 22.00 kg / 48.51 lbs

This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
